Datasheet
Product characteristics
| Electrical design | PNP |
|---|---|
| Output function | normally open |
| Dimensions [mm] | Ø 29 / L = 31 |
Application
| Operating principle | dynamic |
|---|
Electrical data
| Operating voltage [V] | 12…30 DC |
|---|---|
| Current consumption [mA] | 30 |
| Protection class | III |
| Reverse polarity protection | yes |
| Max. power-on delay time [ms] | 500 |
Outputs
| Electrical design | PNP |
|---|---|
| Output function | normally open |
| Permanent current rating of switching output DC [mA] | 200 |
| Short-circuit protection | yes |
| Overload protection | yes |
| Length of output signal [ms] | 300 |
Response times
| Response time [ms] | 35 |
|---|
Operating conditions
| Ambient temperature [°C] | -40…85 |
|---|---|
| Protection | IP 65; IP 67; IP 69K; (on the front) |
Tests / approvals
| MTTF [years] | 352 |
|---|
Mechanical data
| Weight [g] | 55.5 |
|---|---|
| Dimensions [mm] | Ø 29 / L = 31 |
| Materials | PA 6.6-GF30 black; active face: PA Grilamid TR 90UV |
Displays / operating elements
| Display |
|
|---|
Accessories
| Items supplied |
|
||
|---|---|---|---|
| Accessories (optional) |
|
Remarks
| Pack quantity | 1 pcs. |
|---|
Electrical connection – plug
| Connection | Cable: 0.3 m, PUR |
|---|---|
| Connection | Connector: 1 x M12; coding: A |
